industrial flood lights high efficient spot lights for exterior
building 70w 100w
Application
It is suitable for the renovation of large outdoor lighting places
such as port wharf, building exterior wall lighting, high factory
building, outdoor parking lot, outdoor advertisement, highway
bridge, temple and so on.
Key Features & Benefits
1. 50% energy saving compared to ordinary high-pressure sodium
flood lights / metal halide flood lights;
2. Unique optical design, the luminaire efficiency can reach 85%
above.
3. Special design flood light reflector, maximize the utilization
of light source, more effective light and strong lux;
4. The irradiated surface is rectangular, which has a wide range of
irradiation than traditional floodlight, and the irradiation is
even.
5. anti-glare glass cover and reflective design to ensure lighting
to the effective area
6. high power factor, less line loss
7. die-casting aluminum body, light weight, easy maintenance.
8. constant current constant voltage technology, r7xs wire
connection method, extend lamp lifetime 2-3 times than normal hid
flood lights
9. Able to work at 20℃~+85℃ condition area.
10. vertical and horizontal lighting effect available (billboard
advertisement flood light)
11. different beam angle available 7°,11°,22°,33° (315w spot flood
lights)
Our 35W equivalent ordinary 70W
Our 70W equivalent ordinary 100W
Our 100W equivalent ordinary 200W
Our 150W equivalent ordinary 250W
Our 200W equivalent ordinary 400W
Our 315W equivalent ordinary 600W
| Model Number: | NFC-R-MH70-PE1
NFC-R-HS70-PE1 | NFC-R-MH100-PE2
NFC-R-HS100-PE2 | NFC-R-MH150-PM3
NFC-R-HS150-PM3 |
| Lamp Power: | 70W | 100W | 150W |
| Input Voltage: | AC 165 - 265V | AC 165 - 265V | AC 165 - 265V |
| Input Frequency: | 50Hz - 60Hz | 50Hz - 60Hz | 50Hz - 60Hz |
| Power Factor: | > 0.98 | > 0.98 | > 0.98 |
| Color Temperature: | 2000K / 4000K | 2000K / 4000K | 2000K / 4000K |
| Color Rendering Index: | Ra>30 / Ra>80 | Ra>30 / Ra>80 | Ra>30 / Ra>80 |
| Luminous Efficiency: | > 80 lm/w | > 80 lm/w | > 80 lm/w |
| Lumen Maintenance: | 95% | 95% | 95% |
| Average Life: | 24,000 hrs/ 15,000 hrs | 24,000 hrs/ 15,000 hrs | 24,000 hrs/ 15,000 hrs |
| Ballast Type: | Electronic Ballast | Electronic Ballast | Electronic Ballast |
| Lighting Bulbs & Tube: | HPS / MH | HPS / MH | HPS / MH |
| Lampshade Material: | R7S | R7S | R7S |
| Lamp Cover / Diffuser: | Die-casting Aluminum | Die-casting Aluminum | Die-casting Aluminum |
| Reflector: | Heat resistance tempered glass | Heat resistance tempered glass | Heat resistance tempered glass |
| Beam Angle: | high reflective glass reflector | high reflective glass reflector | high reflective glass reflector |
| Lamp Base: | 7°, 11°,22°,33° | 7°, 11°,22°,33° | 7°, 11°,22°,33° |
| Protection: | IP65 | IP65 | IP65 |
| Popular Surface Color: | Black | Black | Black |
| Electrical class: | Class II | Class II | Class II |
| Ambient Temperature: | -35℃ ~ 50℃ | -35℃ ~ 50℃ | -35℃ ~ 50℃ |
| Ambient Humidity: | 10% - 95% | 10% - 95% | 10% - 95% |
| Certification | CE, ROHS | CE, ROHS | CE, ROHS |
| Application: | outdoor lighting, parking lot, exterior building | outdoor lighting, parking lot, exterior building | outdoor lighting, parking lot, exterior building |
| Energy Saving Comparison: | 150W HPS MH Flood Lights | 200W HPS MH Flood Lights | 250W HPS MH Flood Lights |
| Brand Name: | 1/3, OEM | 1/3, OEM | 1/3, OEM |
| Place of Origin: | Guangdong, China Mainland | Guangdong, China Mainland | Guangdong, China Mainland |
